Dell PowerEdge C6220 II Hardware Owner's Manual

About Your System | 47
Sensor Data Record
Event Log Only: the sensor will be only used to explain event log, and will
show disable about sensor state.
Record
ID
Sensor
Numbe
Sensor
Name
Sensor
Ty
pe
Event/Reading
Type
Offset
0004h
0x01
SEL Fullness
Event Logging
Disabled (10h)
Sensor-specific (6Fh)
SI: 67h SC: 40h AM:
0035h DM: 0000h
RM: 0035h
0001h
0x02
P1
ThermalTrip
Processor (07h)
Sensor-specific (6Fh)
SI: 01h SC: 40h AM:
0002h DM: 0000h
RM:
0002h
0002h
0x03
P2
ThermalTrip
Processor (07h)
Sensor-specific (6Fh)
SI: 01h SC: 40h AM:
0002h DM: 0000h
RM: 0002h
0003h
0x04
CPU ERR2
Processor (07h)
Sensor-specific (6Fh)
SI: 01h SC: 40h AM:
0001h DM: 0000h
RM: 0001h
0005h
0x05
12V Standby
Voltage (02h)
Threshold (01h)
SI: 7Fh SC: 59h AM:
7A95h DM: 7A95h
TM: 3F3Fh
NOTE: The abbreviations used in the following table are:
SI: Sensor Initialization DM: Deassertion Mask
SC: Sensor Capabilities RM: Reading Mask
AM: Assertion Mask TM: Settable/Readable Threshold Mask

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
