204 | Installing System Components
Installing the LSI 9265-8i RAID Battery Assembly
1 Attach the LSI9265-8i RAID battery assembly onto the LSI9265-8i
RAID battery tray. See Figure 3-34.
2 Tighten the screw securing the LSI9265-8i RAID battery assembly. See
Figure 3-34.
3 Connect the cable connecting to the LSI 9265-8i card.
4 When replacing the LSI9265-8i RAID battery assembly for 1U node,
skip to step 7; for 2U node, continue the steps.
5 Replace the interposer-extender tray. See “Removing the Interposer
Extender Tray” on page 174.
6 Replace the interposer extender for 2U node. See “Removing the
Interposer Extender for 2U Node” on page 172.
7 Install the system-board assembly. See “Installing a System-Board
Assembly” on page 164.
Removing the LSI 9265-8i RAID Battery
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
NOTE: The information in this section applies only to systems with the optional
1 Remove the system-board assembly. See “Removing a System-Board
Assembly" on page 163.
2 Disconnect the cable connecting to the LSI 9265-8i card.
3 When removing the LSI 9265-8i RAID battery for 1U node, skip to
step 6; for 2U node, continue the steps.
4 Remove the interposer extender for 2U node. See “Removing the
Interposer Extender for 2U Node” on page 172.
5 Remove the interposer-extender tray for 2U node. See “Removing the
