Dell PowerEdge C6220 II Hardware Owner's Manual

276 | Installing System Components
Item
Cable
From
(Bottom Middle Plane)
To
(Expander Card)
Hard-drive
backplane
cable
Mini-SAS connector for
system board 1 (J1)
Mini-SAS connector
( 4~7) for system
board 1
Hard-drive
backplane
cable
Mini-SAS connector for
system board 3 (J3)
Mini-SAS connector
(12~15) for system
board 3
Direct Backplanes
NOTE: Following is the replacement procedure of SATA2 and SAS Direct
Backplane for 3.5-inch hard drive systems. Replacement procedure for 2.5-inch of
SATA2 and SAS Direct Backplane is similar to the Direct Backplane for 3.5-inch
hard drive systems.
Removing the Direct Backplane
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
1 It is recommended to turn off the system, including any attached
peripherals, and disconnect the system from its electrical outlet.
2 Remove all the hard drives. See “Removing a Hard-Drive Carrier” on
page 156.
3 Open the system. See “Opening the System” on page 246.
CAUTION: To prevent damage to the drives and backplane, you must remove the
hard drives from the system before removing the backplane.
CAUTION: You must note the number of each hard drive and temporarily label
them before removal so that you can replace them in the same locations.

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
