Power and System Board Indicator Codes
The LEDs on the system front panel and back panel display status codes
during system startup. For location of the LEDs on the front panel, see
Figure 1-1 for 3.5” hard drive and Figure 1-4 for 2.5” hard drive systems. For
location of the LEDs on the back panel, see Figure 1-14 and Figure 1-15.
Table 1-3 lists the status associated with the status codes.
Table 1-3. Status Indicator Codes
Component Indicator Condition
Power-on
indicator
(A bi-color LED
on power button)
Green Solid
Power On (S0)
Amber Off
Green Off BMC critical condition event in Power
Off mode (S4/S5)
Amber Blinking
Green Off BMC critical condition event in Power
On mode (S0)
Amber Blinking
System
identification
indicator
Steady Blue IPMI via Chassis Identify Command On
or ID Button Press ID On
Blinking Blue Only IPMI via Chassis Identify
Command Blink On
Off IPMI via Chassis Identify Command Off
or ID Button Press ID Off

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
