40 | About Your System
Byte
Field
Value
Description
10 Event Data3 XXh DIMM bit-map locatation of
bits
Bit 0=1: DIMM1 error event
Bit 1=1: DIMM2 error event
…
Bit7=1: DIMM8 error event
PCI-E Error
Message: “Critical Interrupt Sensor, PCI PERR, Device#, Function#, Bus#
“
Byte
Field
Value
Description
1 NetFunLun 10h
2 Platform Event Command 02h
3 Generator ID 01h Generated by BIOS
4 Event Message
Format Version
04h Event Message Format
Revision. 04h for this
specification.
5 Sensor Type 13h Critical Interrupt
6 Sensor Number 73h PCI Sensor ID (depend on
platform)
7 Event Direction
Event Type
6Fh Bit 7: 0 = Assert Event
Bit 6: 0 = Event Type Code
8 Event Data1 AXh 04h: PCI PERR
05h: PCI SERR
07h: Bus Correctable Error
08h: Bus Uncorrectable Error
0Ah: Bus Fatal Error
9 Event Data2 XXh Bit 7:3Device Number
Bit 2:0Function Number
10 Event Data3 XXh Bit 7:0 Bus Number
