Dell PowerEdge C6220 II Hardware Owner's Manual

1
About Your System | 13
About Your System
Accessing System Features during Startup
The following keystrokes provide access to system features during startup.
Note that the hot-keys of SAS/SATA card or PXE support are available in
BIOS boot mode only. There is no hot-key to boot through the UEFI mode.
Keystroke
Description
<F2>
Enters the System Setup program. See “Start Menu” on page 68.
<F11>
Enters the BIOS Boot Manager. See “Boot Manager” on page 69.
<F12>
Starts Preboot eXecution Environment (PXE) / iSCSI boot.
<Ctrl><C>
Enters the LSI 9210-8i HBA Card or LSI 2008 SAS Mezzanine
Card Configuration Utility. For more information, see the SAS
adapter documentation.
<Ctrl><H>
Enters the LSI 9265-8i Card Configuration Utility. For more
information, see the documentation for your SAS RAID card.
<Ctrl><Y>
Enters the MegaPCLI SAS RAID Management Tool.
<Ctrl><S>
Enters the utility to configure onboard LAN settings for PXE
boot. For more information, see the documentation for your
integrated LAN.
<Ctrl><I>
Enters onboard SATA Controller’s Configuration Utility.
<Ctrl><D>
Enter the Intel iSCSI setup menu.

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
