Dell PowerEdge C6220 II Hardware Owner's Manual

194 | Installing System Components
Removing the LSI 9265-8i Card for 2U Node
NOTE: The LSI 9265-8i card assembly should include the BBU interposer card
which is connected to the LSI 9265-8i RAID battery. The illustrations in this section
are just for your removal and installation reference. For more information of the
LSI 9265-8i RAID battery, see “LSI 9265-8i RAID Battery” on page 201.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
NOTE: The LSI 9265-8i card can be supported only on the 1.5U riser card. For the
information of the riser card, see “Removing the Riser card for 2U Node on page
210.
1 Remove the system-board assembly. See “Removing a System-Board
Assembly" on page 163.
2 Disconnect the two SAS/SGPIO cables connecting to the LSI 9265-8i
card assembly.
3 Remove the five screws that secure the LSI 9265-8i card assembly. See
Figure 3-28.
4 Lift the LSI 9265-8i card assembly out of the system-board assembly.
See Figure 3-28.

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
