Dell PowerEdge C6220 II - RAID Card; Summary of LSI 9265-8 I with RAID Battery, LSI 9210-8 I HBA and LSI 9285-8 E with RAID Battery

186 | Installing System Components
RAID Card
The installation and removal procedures and cable routing for the RAID
Cards including LSI 9265-8i with BBU, LSI 9210-8i HBA and LSI 9285-8e
with BBU are similar; refer to the indications for details.
Summary of LSI 9265-8i with RAID Battery, LSI 9210-8i HBA and LSI
9285-8e with RAID Battery
Card Removal
and Installation
BBU Removal
and Installation
Cable Plan
LSI 9265-8i
with RAID
Battery
See “LSI 9265-
8i Card ”
See “ LSI 9265-
8i RAID
Battery
”
Cable required for 1U Node:
• Mini-SAS cable
• Mini-SAS /SGPIO cable
• RAID battery cable
Cable required for 2U Node:
• Mini-SAS /SGPIO cable
• Mini-SAS cable
• RAID battery cable
•
Power cable
LSI 9210-8i
HBA
Same as LSI
9265-8i, see “LSI
9265-8i Card ”
No RAID Battery
Cable required for 1U Node:
• Mini-SAS cable
• Mini-SAS /SGPIO cable
Cable required for 2U node:
• Mini-SAS cable
• Mini-SAS /SGPIO cable
•
Power cable
LSI 9285-8e
with RAID
Battery
Same as
Expansion-Card,
see Figure 3-18
and Figure 3-21
Same as LSI
9265-8i, See “ LSI
9265-8i RAID
Battery ”
Cable required for 1U Node:
• RAID battery cable
Cable required for 2U Node:
• RAID battery cable
• Power cable
Cable Routing
• For cable routing inside 1U node, see “Cable Routing for LSI 9265-
8i Card (1U Node)”.
• For cable routing inside 2U node, see “Cable Routing for LSI 9265-
8i Card (2U Node)”.
