Dell PowerEdge C6220 II Hardware Owner's Manual

238 | Installing System Components
System Board
Removing a System Board
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
1 Remove the system-board assembly. See “Removing a System-Board
Assembly" on page 163.
2 Remove the air baffle. See “Removing the Air Baffle” on page 165.
3 Remove the expansion-card assembly. See “Removing the Expansion
Card” on page 176.
4 Remove the heat sinks. See “Removing the Heat Sink” on page 167.
5 Remove the memory modules. See “Removing the Memory Modules”
on page 232.
6 If installed, remove the SAS mezzanine card, 1GbE mezzanine card, or
10GbE mezzanine card. See “Removing the LSI 2008 SAS Mezzanine
Card” on page 214, “Removing the 1GbE Mezzanine Card” on page
221 and “Removing the 10GbE Mezzanine Card” on page 224.
7 Disconnect all the cables from the system board.
8 Remove the eight screws and then slide the system board. See Figure 3-
61.
CAUTION: Do not lift the system board by grasping a memory module, processor,
or other components.
9 Grasp the system board by the edges and lift the system board away
from the system-board assembly. See Figure 3-61.

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
