180 | Installing System Components
Figure 3-20. Removing the Expansion-card Lock Cover for 2U Node
expansion-card lock cover
6 Remove the screw securing the expansion card. See Figure 3-21.
7 Grasp the expansion card by its edges, and carefully remove it from the
riser card. See Figure 3-21.
If you are removing the card permanently, install a metal filler bracket
over the empty expansion slot opening, and close the expansion-card
latch. See Figure 3-21.
NOTE: You must install a filler bracket over an empty expansion slot to maintain
Federal Communications Commission (FCC) certification of the system. The
brackets also keep dust and dirt out of the system and aid in proper cooling and
airflow inside the system.
