About Your System | 19
Table 1-1. Hard-Drive Status Indicators−For 3.5"/2.5” Direct Hard-Drive Backplane
Controller
Hard
Drive Type
Function
Activity LED
Status LED
Green
Green
Amber
Onboard
Controller
SATA2
Drive on-line
Off/
Blinking
when active
On
Off
Fail
Off
On
Off
LSI 9265
/LSI 2008
/LSI 9210
SAS
/SATA2
Slot Empty
Off
Off
Off
Drive On-
line/Access
Blinking
when active
On
Off
Drive Fail
Off
Off
On 150 ms
Off 150 ms
Drive Rebuild
Blinking
when active
On 400 ms
Off 100 ms
Off
Drive Identify
Blinking
when active
On 250 ms
Off 250 ms
Off
