Dell PowerEdge C6220 II Hardware Owner's Manual

Using the System Setup Program | 91
Option
Description
C-States
(Enabled default)
Enabled - The processor can operate in all available
Power C States.
Disabled - There are no C States available for the
processor.
C1E State
(Enabled default)
Enabled - The C1-E is enabled by default.
Disabled - The C1-E is disabled by users in their own
liability.
There will be warning message in both the BIOS Setup
help text and the pop up message when the option is
changing.
C6 State
(Enabled default)
Enabled - The C6 is disabled by default.
Disabled - The C6 is disabled by user in their own
liability.
There will be warning message in both the BIOS Setup
help text and the pop up message when the option is
changing.
C7 State (If support)
(Enabled default)
Enabled-The C7 is enabled by default.
Disabled-The C7 is disabled by users in their own
liability.
There will be warning message in both the BIOS Setup
help text and the pop up message when the option is
changing.
XD Bit Capability
(Enabled default)
Intel processors that support the eXecute Disabled
(XD) feature will Enable/ Disable report the support to
the operating system.
If the operating system supports this extended paging
mechanism, it will provide some protection against
software viruses that exploit.
Direct Cache Access
(Enabled default)
Enables/Disables the Direct Cache Access.
Hyper Threading Technology
(Enabled default)
Enables/Disables Hyper-Threading Technology.

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
