Dell PowerVault TL2000 - Operator Control Panel Navigation

Table 5-1. Menu navigation shortcuts (continued)
Information/
Activity
Menu Navigation Shortcuts
Operator Control Panel For More Info Web User Interface For More Info
Slots, number
empty
Monitor → Library → Status “Monitor:
Library” on
page 5-10
System Status screen
Slots, reassign
number of active,
reserving
Note: Varies according to the
number logical libraries.
Single partition: Configure →
Logical Library Settings
Multiple partitions: Configure →
Logical Library Settings →
Logical Library (n)
“Configure:
Library” on
page 5-20
Configure Library →
General
“Configure
Library: General”
on page 5-44
SNMP, modify
settings
Not available with this
interface.
Configure Library →
SNMP
“Configure
Library: SNMP”
on page 5-56
Telnet Service
Port, activate
Service → Telnet Service Port “Service:
Telnet Service
Port” on page
5-33
Not available with this
interface.
Time elapsed
since power ON
Monitor → Library → Status “Monitor:
Library” on
page 5-10
Monitor Library → Library
Status
“Monitor Library:
Library Status” on
page 5-37
Operator Control
Panel, access
PIN,
enable/disable
Configure → Set Access PIN “Configure:
Set Access
PIN” on page
5-25
Not available with this
interface.
Web User
Interface, user
access, create or
modify
Not available with this
interface.
Configure Library → User
Access
“Configure
Library: User
Access” on page
5-52
Operator Control Panel Navigation
The four control keys on the front of a 2U or 4U library enable the user to navigate
through the library settings and make changes as needed to configure the library.
Chapter 5. Operations 5-7
