Table 1-2. 2U library and 4U library rear panel descriptions (continued)
Number Item Description
4 Shipping lock and
label storage
location
The shipping lock, which secures the accessor during shipping, and associated
label are stored on the rear panel of the library for future use. See “Removing and
Storing the Shipping Lock” on page 4-4.
Note: The shipping lock must be removed before powering ON the library to
allow the accessor to function properly.
5 USB port Used to save/restore library configuration information on a USB device.
6 Library Control
Board (LCC) LED
An LED showing the status of the Library Control Board.
LED flashing (1 flash per second) - normal operation
7 Serial port This port is used to communicate serially with the library using an RJ-11 connector.
For use by Service Personnel.
8 Ethernet port This port is used to connect the library to a network.
9 Tape drive LED This LED indicates the current status of the drive. When the LED is green, it
indicates normal drive activity.
10 Service Tag/Serial
Number
The service tag and serial number on the pull-out label links the library to your
warranty.
11 Fan vents These vents allow air to escape from the power supply and tape drive sled.
Bar Code Reader
The bar code reader is an integral part of the library accessor. The bar code reader
provides inventory feedback to the host application, Operator Control Panel
display, and Web User Interface by reading cartridge bar code labels. The library
stores the customized inventory data in memory.
Library firmware supportsa6or8character volume serial number (VOLSER) on
the bar code label on the tape cartridge. Bar code selection is available for libraries
with library code 4.50 or greater.
Encryption
The LTO Ultrium 5 Tape Drive supports Application Managed Encryption (AME),
and Library Managed Encryption (LME), using T10 encryption methods, for SAS
and Fibre Channel drives only. Data encryption is supported with LTO Ultrium 4
and Ultrium 5 Data Cartridges only. Encryption is also supported with library
firmware version 5.80 and higher and drive firmware version 77BE for LTO 4 and
higher drive code level.
The encryption enabled drive contains the necessary hardware and firmware to
encrypt and decrypt host tape application data. Encryption policy and encryption
keys are provided by the host application or host server. A drive digital certificate
is installed at manufacturing time. Each drive receives a unique serial number and
certificate. The T10 application may validate each drive instance by checking the
drive's digital certificate.
