Dell PowerVault TL2000 - Sliding the 4 U Library into the Rack; Securing the 2 U Library to the Rack

8. Using a #2 Phillips screwdriver, secure the library to the rack (see Figure 4-11
for a 2U library; see Figure 4-12 on page 4-11 for a 4U library) by placing a
screw in the center hole of each mounting bracket and tightening them (
1
).
a77ug109
Figure 4-10. Sliding the 4U library into the rack
a77ug12
8
1
Figure 4-11. Securing the 2U library to the rack
4-10 Dell PowerVault TL2000 Tape Library and TL4000 Tape Library User's Guide
