External ports and slots
The following table lists the external ports and slots of your Dell Pro 14 Plus.
Table 7. External ports and slots
Description Values
Network port
Not applicable
USB ports
● Two Thunderbolt4 ports with DisplayPort Alt Mode/USB
Type-C/USB4/Power Delivery
NOTE: You can connect a Dell Docking Station to
these ports. For more information, search in the
Knowledge Base Resource at Dell Support site.
●
One USB 3.2 Gen 1 port with PowerShare
● One USB 3.2 Gen 1 port
Audio port
One Global headset jack
Video port(s)
One HDMI 2.1 TMDS
Media-card reader
One smart card reader slot (optional)
Power-adapter port
Supported through USB-C
Security-cable slot
One wedge-shaped security slot
SIM-card slot
Nano-SIM card slot (optional)
Internal slots
The following table lists the internal slots of your Dell Pro 14 Plus.
Table 8.
Internal slots
Description Values
M.2
● One M.2 2230 or M.2 2280 solid state drive slot
● One M.2 3052 for WWAN slot (optional)
NOTE: To learn more about the features of different
types of M.2 cards, search in the Knowledge Base
Resource at Dell Support Site.
Wireless module
The following table lists the Wireless Local Area Network (WLAN) module that is supported on your Dell Pro 14 Plus.
Table 9.
Wireless module specifications
Description Values
Model number
Intel Wi-Fi 7 BE201
Transfer rate
Up to 5760 Mbps
Specifications of Dell Pro 14 Plus 17
