9. Install the SIM card tray, if required.
10. Follow the procedure in after working inside your computer .
Smart-card reader
Removing the smart card reader
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the sim-card tray, if applicable.
3. Remove the base cover.
4. Remove the battery.
5. Remove the speakers.
About this task
NOTE: This procedure applies only to computers shipped with a smart card reader installed.
The following images indicate the location of the smart card reader and provide a visual representation of the removal
procedure.
Removing and installing Field Replaceable Units (FRUs)
93
