Display back cover
Removing the display back cover
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the sim-card tray, if required.
3. Remove the base cover.
4. Remove the WWAN.
NOTE: This procedure applies only to computers shipped with a WWAN card installed.
5. Remove the display assembly.
6. Remove the display bezel.
7. Remove the display panel .
8. Remove the camera cable (for models shipped without camera or with RGB or IR camera).
9. Remove the MIPI camera cable (for models shipped with MIPI camera).
10. Remove the display hinge cap and hinge assembly.
About this task
The following images indicate the location of the smart card reader and provide a visual representation of the removal
procedure.
Removing and installing Field Replaceable Units (FRUs)
91
