Display hinges
Removing the display hinge cap and hinge assembly
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the sim-card tray, if applicable.
3. Remove the base cover.
4. Remove the WWAN.
NOTE: This procedure applies only to computers shipped with a WWAN card installed.
5. Remove the display assembly.
6. Remove the display bezel.
7. Remove the display panel .
About this task
The following images indicate the location of the display hinges and provide a visual representation of the removal procedure.
82
Removing and installing Field Replaceable Units (FRUs)
