Removing and installing Field Replaceable
Units (FRUs)
The replaceable components in this chapter are Field Replaceable Units (FRUs).
CAUTION: The information in this section is intended for authorized service technicians only.
CAUTION: To avoid any potential damage to the component or loss of data, ensure that an authorized service
technician replaces the Field Replaceable Units (FRUs).
CAUTION: Dell Technologies recommends that this set of repairs, if needed, to be conducted by trained
technical repair specialists.
CAUTION: As a reminder, your warranty does not cover damages that may occur during FRU repairs that are not
authorized by Dell Technologies.
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Display assembly
Removing the display assembly
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the sim-card tray, if applicable.
3. Remove the base cover.
4. Remove the WWAN.
NOTE:
This procedure applies for models that are shipped without a camera or models that are shipped with an RGB or
IR camera.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
6
Removing and installing Field Replaceable Units (FRUs) 63
