Supports USB4, DisplayPort 2.1, Thunderbolt 4 and also enables you to connect to an external display using a display adapter.
Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4.
NOTE: You can connect a Dell Docking Station to the Thunderbolt 4 ports. For more information, search in the
Knowledge Base Resource at Dell Support Site.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
NOTE: Thunderbolt 4 supports two 4K displays or one 8K display.
4. Battery-status light
Indicates the battery-charge status.
● White-Battery is charging.
● Solid yellow-Battery charge is low.
● Blinking yellow-Battery charge is critical.
● Off—Battery is fully charged.
5. Smart-card reader slot (optional)
Using smart card provides authentication in corporate networks.
Top
Figure 3. Top view
1. Power button with optional fingerprint reader
8
Views of Dell Pro 14 Plus
