5. Follow the procedure in after working inside your computer.
Display panel
Removing the display panel
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the sim-card tray, if required.
3. Remove the base cover.
4. Remove the display assembly.
5. Remove the display bezel.
About this task
NOTE: This procedure applies for only models that are shipped with an RGB or IR camera.
The following images indicate the location of the display cable and camera assembly and provide a visual representation of the
removal procedure.
76
Removing and installing Field Replaceable Units (FRUs)
