Dell Pro 14 Plus - Fingerprint Reader (Optional); Power Adapter

Fingerprint reader (optional)
The following table lists the specifications of the optional fingerprint-reader of your Dell Pro 14 Plus.
Table 18. Fingerprint reader specifications
Description Values
Sensor technology
Trans-capacitive sensing
Sensor resolution
500/363 dpi
Sensor pixel size
● X: 108 / 76
● Y: 88 / 100
Power adapter
The following table lists the power adapter specifications of your Dell Pro 14 Plus.
Table 19. Power-adapter specifications
Description Option one Option two Option three
Type
60 W adapter, USB-C 65 W adapter, USB-C 100 W adapter, USB-C
Power-adapter dimensions:
Height
22 mm (0.87 in.) 28 mm (1.1 in.) 26.5 mm (1.04 in.)
Width
55 mm (2.16 in.) 51 mm (2.01 in.) 60 mm (2.36 in.)
Depth
66 mm (2.60 in.) 112 mm (4.41 in.) 122 mm (4.80 in.)
Input voltage
100 to 240 VAC 100 to 240 VAC 100 to 240 VAC
Input frequency
50 Hz to 60 Hz 50 to 60 Hz 50 to 60 Hz
Input current (maximum)
1.70 A 1.70 A 1.70 A
Output current (continuous)
● 20 V/3 A (continuous)
● 15 V/3 A (continuous)
● 9.0 V/3 A (continuous)
● 5.0 V/3 A (continuous)
● 20V/3.25A (continuous)
● 15V/3A (continuous)
● 9.0V/3A (continuous)
● 5.0V/3A (continuous)
● 20 V/5 A (continuous)
● 15 V/3 A (continuous)
● 9.0 V/3 A (continuous)
● 5.0 V/3 A (continuous)
Rated output voltage
20 VDC/15 VDC/9 VDC/5
VDC
20 VDC/15 VDC/9 VDC/5
VDC
20 VDC/15 VDC/9 VDC/5
VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F) 0°C to 35°C (32°F to 95°F)
Storage
-20°C to 70°C (-4°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Specifications of Dell Pro 14 Plus 23
