NOTE: This procedure applies only to computers shipped with a WWAN card installed.
5. Install the base cover.
6. Install the SIM card tray, if applicable.
7. Follow the procedure in after working inside your computer.
MIPI camera
Removing the MIPI camera
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the sim-card tray, if applicable.
3. Remove the base cover.
4. Remove the WWAN.
NOTE: This procedure applies only to computers shipped with a WWAN card installed.
5. Remove the display assembly.
6. Remove the display bezel.
7. Remove the display panel .
About this task
NOTE: This procedure applies for only models that are shipped with MIPI camera.
The following image indicates the location of the MIPI camera and provides a visual representation of the removal procedure.
Figure 56. Removing the MIPI camera
Removing and installing Field Replaceable Units (FRUs)
85
