3. Remove the battery.
4. Remove the memory module.
5. Remove the M.2 2230 solid-state drive or M.2 2280 solid-state drive, whichever is applicable.
6. Remove the wireless card.
7. Remove the WWAN module, if available.
8. Remove the speakers.
9. Remove the right/processor fan.
10. Remove the left/video fan.
11. Remove the heat sink.
NOTE: If you are removing the system board to replace/access other parts, you may remove the system board with the
heat sink attached to it in order to simplify the procedure and preserve the thermal bond between the system board and
heat sink.
12. Remove the GPU filler.
13. Remove the system board.
NOTE: If you are removing the system board to replace/access other parts, you may remove the system board with the
heat sink attached to it in order to simplify the procedure and preserve the thermal bond between the system board and
heat sink.
14. Remove the power button.
About this task
The following images indicate the location of the keyboard and provide a visual representation of the removal procedure.
