Cyclic Synchronous Position Mode (CSP) EtherCAT Programming Guide
9-6 March, 2017
9
Description
Linear interpolation of CSP command (acc/deceleration)
V
(pps)
T
(sec)
Start
Velocity
Constant
Velocity
End
Velocity
TPhase1
TPhase2
Figure 9.1.1 Perform lineter interpolation by referring to relative coordinates (T-curve)
V
(pps)
T
(sec
)
Start
Velocity
End
Velocity
Constant
Velocity
TPhase1 TPhase2
Figure 9.1.2 Perform linear interpolation by referring to relative coordinates (S-curve)
