 “3: OPEN “COM:” DETAIL”: Setting the OPEN “COM:” communication conditions
The system mode settings can be used for the communication conditions of the user program (OPEN
“COM:”) developed with BHT-BASIC. This eliminates the need to change the user program and thus to
rewrite the communication conditions in changing the communication speed.
1. Select “3: OPEN “COM:” DETAIL” at the SET COMMUNICATION menu and then press the ENT
key.
The OPEN “COM:” DETAIL menu on the right is displayed.
The highlighted setting is the current setting.
“1: SETTINGS FROM”:
Sets up the setting values specified by the user program or the system
mode settings of the communication conditions of the user program (OPEN
“COM:”).
“API”:
Uses the setting value specified by the user program (default).
“SYSTEM”:
Uses the setting value of the system mode (the setting value specified by the user program is not
used).
Communication conditions
System mode setting screen
(SET COMMUNICATION menu)
API
Interface *1
COM1
OPEN "COM:"*2
Transmission speed
“1: COM1”
↓
“1: PARAMETER”
↓
“1: TRANSMIT SPEED”
Serial communication
protocol
“2: PROTOCOL TYPE” Out .pnCmPrtcl (6060)
*1 If COM3 or COM4 is specified by the user program, the setting value of “1:SETTINGS FROM” is
ignored.
*2 Operation is conducted at COM1 when COM2 is specified
OPEN
"
COM:
"
DETAIL
1：SETTINGS FROM
API SYSTEM
