Denso BHT-1505B - 9.1 CU-A*1-15 Specifications

220
BHT-1500B Series
9.1 CU-A*1-15 Specifications
9.1.1 Hardware Specifications
CU-AR1-15
CU-AL1-15
CU-AU1-15
Power supply:
100 V AC
(Using dedicated AC
adapter)
100 V AC
(Using dedicated AC
adapter)
Powered from the USB
interface *
Max. power consumption:
1.5 A at 5V 1.5 A at 5V 1.5 A at 5V*
500 mA at 5V
Dimensions (W) x (L) x (H)
: 95 x 110 x 98 mm
Weight:
170g 171g 166 g
Ambient operating temperature:
0 to 40° C
Ambient operating
humidity: 20% to 80% (with no dew condensation)
* The CU-AU1-15 can also be powered from the AC adapter.
9.1.2 Charging Requirements (CU-AR1-15, -AL1-15 and -AU1-15)
Charge current: Approx. 300 mA
Charging time: Approx. 5 hours
The above-mentioned charger current and charging time are reference values at normal temperature.
