[2] Uploading the system message file
1. Use the cursor keys ([▲] [▼]) or numerical key ([2]) to highlight [2:
UPLOAD] and then press the ENT key.
The screen on the right indicating that the BHT is waiting for the system
message file to be uploaded is displayed.
2. While the upload is in progress, the screen on the right indicating the
file name and the number of sent records/the total number of records
is displayed.
Press the BS/C key to abort the upload and return to the SYSTEM
MESSAGE menu.
3. Upon completion of uploading, the screen on the right is displayed
and the sepaker beeps once.
Press and hold the BS/C key to return to the SYSTEM PARAMETER menu.
The buzzer sounds three times if an error occurs during uploading, and an
error screen is displayed.
Refer to “Chapter 7 Error Messages” - “7.2 System Mode Errors” and
remedy the error.
- Point -
When uploading the system message file, the BHT creates a
temporary file named “_B
15
MSG.FN3” in the user area. An
error will therefore occur if there is insufficient space in the
user area to create the temporary file.
The created temporary file will automatically be deleted after
uploading is complete.
