 Setting up the master station
1. Select “3: MASTER” at the SET BLUETOOTH menu and then press
the ENT key.
The current settings are displayed.
[1: PEER BD_ADDR]: Sets up the remote device address of the connection
target.
[2: PASSKEY]: Sets up the Bluetooth
®
passkey for the master
station
[3: TIMEOUT]: Sets up the timeout period for connecting to the
master station in seconds.
[4: SECURITY]: Sets up the security mode for the master station.
Press and hold the BS/C key to return to the SET BLUETOOTH menu.
2. Use the cursor keys ([▲] [▼]) or numeric keys ([1] [2] [3] [4]) to select the menu and then press
the ENT key.
Entry mode is activated and the cursor is displayed.
To set up the “4: SECURITY”, use the cursor keys ([◄] [►]) to highlight and set the desired setting.
3. Use the numeric and period (.) keys to enter the desired value.
“PEER BD ADDR”: The key Input and reading barcode is available.
Input Key:Input 12-digit hexadecimal numbers and press ENT key.
The ENT key is not available until the twelfth digit is entered.
Reading barcode:After reading a 12-digit hexadecimal barcode,the input mode is
automaticaly ended.
“PASSKEY”: Up to 16 characters
“TIMEOUT”: Valid Range: 1–255, Default: 30 seconds
For the Bluetooth
®
passkey and the security mode details, refer to Chapter 5 “Communication” – 5.3
“Bluetooth
®
wireless communications”.
To switch the entry mode (between numeric and alphabet entries), press the SF key.
To delete a single character, press the BS/C key. To delete the entire entry, press and hold the BS/C key
or press the SF and BS/C keys simultaneously.
4. Press the ENT key.
5. Press and hold the BS/C key to return the SET BLUETOOTH menu.
