Denso BHT-1505B - System Mode Basic Operation

47
BARCODE Handy Terminal
Select [
4: SET SYSTEM
] with
the [4] key,
[▲] or [▼] keys.
Select [2
: DISPLAY] with the
[2] key,
[▲] or [▼] keys.
1:EXECUTE PROGRAM
2:DISPLAY
3:DATE/TIME
4:BARCODE
5:COMMUNICATION
6:KEY
7:TCP/IP
[ ]NEXT▶
4.4.2 System Mode Basic Operation
Menu Selection and Display
Use the following procedure to select and display each menu.
1. Press the numerical key corresponding to the menu to be selected.
Alternatively, press the cursor keys ([▲] [▼]) to select the menu.
The selected menu item will be highlighted.
“SETUP” will be highlighted when System Mode is started up.
2. Press the ENT key.
The selected item is set and the next screen
is displayed.
Press the BS/C key to return to the previous
screen.
The selected item will be highlighted when
returning to the previous screen.
3. Repeat the above operation to display the target menu.
 Operation example
ENT
key
BS/C key
