BHT-1500B Series
3.1 Reading Barcodes
Follow the procedure below to scan barcodes.
1. Turn the BHT power ON.
2. Press the Scan key.
The BHT emits a guide marker (laser light) and the light for reading.
Hold the BHT close to the code to align the guide marker.
When the BHT has read the code successfully, the indicator LED will illuminate in blue.
−
Note
−

If required, clean dirty labels before reading.

It may not be possible to perform reading in direct sunlight.

If the code is on a curved surface, flatten the label surface and read it again.

If the code reading window is pulled away from the code, the read
able code range will
become narrower than that of the light emission.
−
Point
−
The code
reading method may differ depending on
the application.
Select the most appropriate in
accordance with the instructions provided in the
application User’s Manual.
Power key
Guide marker
