8.1.2 Code Specifications
:
Barcode Type
Bar Dimensions
Scan Magnification
Universal product codes
JAN-13 (EAN-13)
JAN-8 (EAN-8)
UPC-A
UPC-E
JAN-13 (EAN-13) with add-on
JAN-8 (EAN-8) with add-on
UPC-A with add-on
UPC-E with add-on
2-dgit add-on
5-dgit add-on
Min.
0.26 mm
Min.
0.8
Interleaved 2of5 (ITF)
Standard 2of5 (STF
)
Codabar (NW
-7)
Code
39
Min.
0.125 mm
PCS value
≥ 0.9
Black/white bar r
eflection intensity difference ≥ 0.8
Min. 0.15 mm
(
PCS value ≥ 0.45)
Code 93
Code 128, GS1
-128 (EAN-128, UPC-128)
Min. 0.15 mm
PCS value
≥ 0.9
Black/white bar r
eflection intensity difference ≥ 0.8
Min. 0.19
mm
(
PCS value ≥ 0.45)
GS1 DataBar
TM
(RSS)
GS1 DataBar Omnidirectional
GS1 DataBar Truncated
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
GS1 DataBar Limited
GS1 DataBar Expanded
GS1 DataBar Expanded Stacked
Min.
0.15 mm
(
PCS value ≥ 0.9)
Black/white bar r
eflection intensity difference ≥ 0.8
Required Optical Properties
White bars: Reflection intensity of 45% or higher
Black bars: Reflection intensity of 25% or lower
PCS value of 0.45 or higher
The reflection intensity is regulated with a light source with spectral peak of 633 nm and spectrum range of
610 to 650 nm.
