BHT-1500B series
4.5.11 USB Communication Settings (DEVICE MENU)
Use the following procedure to set up USB communication.
[1] Setting up the USB Parameters
1. Select “3: USB” at the DEVICE MENU and then press the ENT key.
The USB MENU screen on the right is displayed.
2. Use the cursor keys ([▲] [▼]) to select the menu and then press the
ENT key.
Press and hold the BS/C key to return to the DEVICE MENU.
“1: SET CONNECT MODE”: Sets up the USB connection mode.
The highlighted setting will be the current setting.
Use the cursor keys ([◄] [►]) to change the setting, and then press the ENT
key.
“MTP”: Connects in the MTP mode.
“COM”: Connects in the COM mode.
−
Point
−
Refer to the following section for the MTP mode.
Refer to “4.5.6 [5] Setting the communication environment” for the COM mode.
[2] Setting up the MTP Parameters
1. Select “MTP” at the USB MENU and then press the ENT key.
The MTP SETTING screen on the right is displayed.
2. Use the cursor keys ([▲] [▼]) or numeric keys ([1][2][3]) to select
the menu and then press the ENT key.
Press and hold the BS/C key to return to the USB MENU.
“1: MTP RESTRICTIONS”: Sets up the MTP RESTRICTIONS screen.
“2: MTP FILE SETTING”: Sets up the MTP FILE SETTING screen.
“3: MTP DISP FILTER”: Sets up the MTP DISP FILTER screen.
Refer to the following section for each of the above menus.
MTP SETTING
1：MTP RESTRICTIONS
2：MTP FILE SETTING
3：MTP DISP FILTER
DEVICE MENU
1：USB
USB MENU
1：SET CONNECT MODE
MTP COM
[ENT]DETAIL
