54
BHT-1500B series
4.5 SYSTEM MENU
4.5.1 Executing Setup (SETUP Menu)
The BHT setup can be effectively executed using the BHT Setting and clone functions.
The following explains setup using two BHTs with the clone function. Use the procedure below for BHT
setup.
1. Select “0: SETUPat the SYSTEM menu and then press the ENT
key.
The screen on the right is displayed.
1: CLONE”:
Select to use two BHTs to create a BHT clone (s).
The clone function resembles the conventional HT-HT copy function,
but differs according to the points in the table below.
2: BHT Setting”:
For details, refer to the BHT Setting Users Manual.
“3: BACKUP”:
Select to back up the data to the microSD card.
SETUP MENU
1CLONE
2BHT Setting
3BACKUP
