CU-Ax1-15 Series (Option)
Used for communication between the BHT and the host computer.
Communication with the host computer is performed with an RS-232C, Ethernet (100BASE-T) or USB
interface. The following three types of CU are available depending on the interface used to communicate
with the host computer.
• CU-AR1-15: RS-232C interface
• CU-AL1-15: Ethernet (100BASE-T) interface
• CU-AU1-15: USB interface
The CU-AR1-15,CU-AL1-15 and CU-AU1-15 communicates with the BHT via USB.
Refer to Chapter 4.5.6 [5] “Setting the communication environment” for each communication setting.
Connection Cable (Option or Commercially Available Product)
Used for connecting the host computer and CU-A*1-15 Series.
Select a cable suited to the CU-A*1-15 Series interface to be used.
Supported CU-Ax1-15 Series Cables
• CU-AR1-15: RS-232C cable (Option)
• CU-AL1-15: Ethernet (10BASE-T) cable (commercially available product)
• CU-AU1-15: USB (USB 2.0 Type A - B) cable (Option)
Bluetooth
®
compatible device (Option)
Used for Bluetooth
®
wireless communication between the BHT and a device such as the Bluetooth
®
compatible host computer, printer, mobile phone, etc.
IrDA compatible device (Option)
Used for establishing IrDA communicaiton with the IrDA-compatible printer.
