Interfaces Local Area Networks (LANs)
Digi Connect IT® 16/48 User Guide
130
d. Configure the IPv4 address for the LAN1 interface:
(config network interface LAN1)> ipv4 address 192.168.3.1/24
(config network interface LAN1)>
e. Enable the DHCP server for the LAN1 interface:
(config network interface LAN1)> ipv4 dhcp_server enable true
(config network interface LAN1)>
4. Create the LAN2 interface:
a. Add the interface:
(config)> add network interface LAN2
(config network interface LAN2)>
b. Configure the LAN2 interface:
i. Enter device ? to view available devices and the proper syntax.
(config network interface LAN2)> device ?
Device: The network device used by this network interface.
Format:
/network/device/eth1
/network/device/eth2
/network/bridge/LAN
/network/bridge/Example_bridge
/network/wireless/ap/digi_ap
/network/wireless/ap/Example_AP
Current value:
(config network interface LAN2)> device
ii. Set the device for the LAN2 interface:
(config network interface LAN2)> device /network/device/eth1
(config network interface LAN2)>
c. Configure the firewall zone for the LAN2 interface to internal:
(config network interface LAN2)> zone internal
(config network interface LAN2)>
d. Configure the IPv4 address for the LAN2 interface:
(config network interface LAN2)> ipv4 address 192.168.4.1/24
(config network interface LAN2)>
e. Enable the DHCP server for the LAN2 interface:
(config network interface LAN2)> ipv4 dhcp_server enable true
(config network interface LAN2)>
