Services Configure a multicast route

Digi Connect IT® 16/48 User Guide

424

Format:

/network/interface/defaultip

/network/interface/defaultlinklocal

/network/interface/eth1

/network/interface/eth2

/network/interface/loopback

/network/interface/sfp1

/network/interface/sfp2

/network/interface/wwan

Current value:

(config service multicast test)> interface

b. Set the interface. For example:

(config service multicast test)> interface /network/interface/eth1

(config service multicast test)>

9. Save the configuration and apply the change:

(config)> save

Configuration saved.

10. Type exit to exit the Admin CLI.

Depending on your device configuration, you may be presented with an Access selection

menu. Type quit to disconnect from the device.
