Digi IX30 User Manual

Interfaces Local Area Networks (LANs)
IX30 User Guide
168
Show LAN status and statistics
Web
1. Log into the IX30 WebUI as a user with Admin access.
2. From the menu, click Status.
3. Under Networking, click Interfaces.
Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the IX30
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. Enter the show network command at the Admin CLI prompt:
> show network
Interface Proto Status Address
---------------- ----- ------- -------------------------------
defaultip IPv4 up 192.168.210.1/24
defaultlinklocal IPv4 up 169.254.100.100/16
eth1 IPv4 up 10.10.10.10/24
eth1 IPv6 up fe00:2404::240:f4ff:fe80:120/64
eth2 IPv4 up 192.168.2.1/24
eth2 IPv6 up fd00:2704::1/48
loopback IPv4 up 127.0.0.1/8
modem IPv4 up 10.200.1.101/30
modem IPv6 down
>
3. Additional information can be displayed by using the show network verbose command:
> show network verbose
Interface Proto Status Type Zone Device Metric
Weight
---------------- ----- ------- ------ -------- -------- ------ --
----
defaultip IPv4 up static setup eth2 10 10
defaultlinklocal IPv4 up static setup eth2 0 10
eth1 IPv4 up dhcp external eth1 1 10
eth1 IPv6 up dhcp external eth1 1 10
eth2 IPv4 up static internal eth2 5 10
eth2 IPv6 up static internal eth2 5 10
loopback IPv4 up static loopback loopback 0 10
modem IPv4 up modem external wwan1 3 10
modem IPv6 down modem external wwan1 3 10

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
