Digi IX30 hardware reference IX30 LEDs
IX30 User Guide
25
Number Item Decription
certificates/keys.
3. Firmware reversion: Press and hold the ERASE button and
then power on the device to boot to the version of firmware
that was used prior to the current version.
9 USB port
10 ETH2
Ethernet port, LAN-enabled by default
11 WAN/ETH1
Ethernet port, WAN-enabled by default.
IX30 LEDs
The IX30 LEDs are located on the top front panel. The number of LEDs varies by model. During
bootup, the front-panel LEDs light up in sequence to indicate boot progress.
POWER
Off
No power.
Solid green
Device has power but is not connected to the
internet.
Flashing green/cyan
Device has power and is in the process of
connecting to the internet.
Solid cyan
Device has power and is connected to the internet.
LTE
Indicates that the status of the cellular module and the ETH2 Ethernet port connection:
