Diagnostics Analyze network traffic
IX30 User Guide
947
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. Type the following at the Admin CLI prompt:
> analyzer stop name capture_filter
>
where capture_filter is the name of a packet capture configuration. See Configure packet
capture for the network analyzer for more information.
To determine available packet capture configurations, use the ?:
> analyzer stop name ?
name: Name of the capture filter to use.
Format:
test_capture
capture_ping
> analyzer stop name
Show captured traffic data
To view captured data traffic, use the show analyzer command. The command output show the
following information for each packet:
n
The packet number.
n
The timestamp for when the packet was captured.
n
The length of the packet and the amount of data captured.
n
Whether the packet was sent or received by the device.
n
The interface on which the packet was sent or received.
n
A hexadecimal dump of the packet of up to 256 bytes.
n
Decoded information of the packet.
To show captured data traffic:
Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the IX30
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. Type the following at the Admin CLI prompt:
> show analyzer name capture_filter
Packet 1 : Nov-28-2022 19:48:00.287682, Length 60 bytes (Captured Length
60 bytes)
Received on interface eth1
