Digi IX30 hardware reference Digi IX30 serial connector pinout
IX30 User Guide
31
IX30 RS-232 pinout
DB9 pin Pin direction RS-232 function
1 Input DCD
2 Input RxD
3 Output TxD
4 Output DTR
5 Ground
6 Input DSR
7 Output RTS
8 Input CTS
9 Input RI
IX30 RS-422 pinout
DB9 pin Pin direction RS-422 function
1 Input CTS-
2 Input RXD+
3 Output TXD+
4 Output RTS-
5 Ground
6 Input RXD-
7 Output RTS+
8 Input CTS+
9 Output TXD-
IX30 RS-485 pinout
DB9 pin Pin direction RS-485 function
1
2 Input/Output High (internally connected to pin 3)
3 Input/Output High (internally connected to pin 2)
4

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
