Digi IX30 User Manual

Serial port Configure Login mode
IX30 User Guide
212
n
rs-232
n
rs-422
l
Enable Termination if you want to enable electrical termination on this serial port.
n
rs-485
l
Enable termination if you want to enable electrical termination on this serial port:
(config)> serial port1 termination true
(config)>
The default is rs-232.
6. (Optional) Set a label that will be used when referring to this port.
(config)>path-paramlabel label
(config)>
7. Set the baud rate used by the device to which you want to connect:
(config)>path-parambaudrate rate
(config)>
8. Set the number of data bits used by the device to which you want to connect:
(config)>path-paramdatabits bits
(config)>
9. Set the type of parity used by the device to which you want to connect:
(config)>path-paramparity parity
(config)>
Allowed values are:
n
even
n
odd
n
none
The default is none.
10. Set the stop bits used by the device to which you want to connect:
(config)>path-paramstopbits bits
(config)>
11. Set the type of flow control used by the device to which you want to connect:
(config)>path-paramflow value
(config)>
where value is one of:
n
none
n
rts/cts
n
xon/xoff

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
