Digi IX30 User Manual

Serial port Configure UDP serial mode
IX30 User Guide
243
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. The serial port is enabled by default. To disable:
(config)> serial port1 enable false
(config)>
4. Set the mode:
(config)> serial port1 mode udp
(config)>
5. Set the signaling interface type used on this serial port:
n
rs-232
n
rs-422
l
Enable Termination if you want to enable electrical termination on this serial port.
n
rs-485
l
Enable termination if you want to enable electrical termination on this serial port:
(config)> serial port1 termination true
(config)>
The default is rs-232.
6. (Optional) Set a label that will be used when referring to this port.
(config)>serial port1 label label
(config)>
7. Set the baud rate used by the device to which you want to connect:
(config)>serial port1 label baudrate rate
(config)>
8. Set the number of data bits used by the device to which you want to connect:
(config)>serial port1 label databits bits
(config)>
9. Set the type of parity used by the device to which you want to connect:
(config)>serial port1 label parity parity
(config)>
Allowed values are:

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
