Digi IX30 User Manual

Virtual Private Networks (VPN) Generic Routing Encapsulation (GRE)
IX30 User Guide
443
10. Save the configuration and apply the change:
(config vpn ipsec tunnel ipsec_gre2 policy 0)> save
Configuration saved.
>
Task two: Create an IPsec endpoint interface
Web
1. Click Network > Interfaces.
2. For Add Interface, type ipsec_endpoint2 and click .
3. For Zone, select Internal.
4. For Device, select Ethernet: loopback.
5. Click to expand IPv4.
6. For Address, type the IP address of the local GRE tunnel, 172.30.0.2/32.
7. Click Apply to save the configuration and apply the change.
Command line

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
