Digi IX30 User Manual

Virtual Private Networks (VPN) L2TP
IX30 User Guide
452
l
A single IP address or host name.
l
A network designation in CIDR notation, for example, 192.168.1.0/24.
l
any: No limit to IPv4 addresses that can access the service-type.
Repeat this step to list additional IP addresses or networks.
n
To limit access to specified IPv6 addresses and networks:
(config)> add vpn l2tp acl address6 end value
(config)>
Where value can be:
l
A single IP address or host name.
l
A network designation in CIDR notation, for example, 2001:db8::/48.
l
any: No limit to IPv6 addresses that can access the service-type.
Repeat this step to list additional IP addresses or networks.
n
To limit access to hosts connected through a specified interface on the IX30 device:
(config)> add vpn l2tp acl interface end value
(config)>
Where value is an interface defined on your device.
Display a list of available interfaces:
Use ... network interface ? to display interface information:
(config)> ... network interface ?
Interfaces
Additional Configuration
-------------------------------------------
defaultip Default IP
defaultlinklocal Default Link-local IP
eth1 ETH1
eth2 ETH2
loopback Loopback
modem Modem
(config)>
Repeat this step to list additional interfaces.
n
To limit access based on firewall zones:
(config)> add vpn l2tp acl zone end value
(config)>
Where value is a firewall zone defined on your device, or the any keyword.
Display a list of available firewall zones:
