Digi IX30 User Manual

Services Configure a multicast route
IX30 User Guide
592
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add the multicast route. For example, to add a route named test:
(config)> add service multicast test
(config service multicast test)>
4. The multicast route is enabled by default. If it has been disabled, enable the route:
(config service multicast test)> enable true
(config service multicast test)>
5. Set the source address for the route. This must be a multicast IP address between 224.0.0.1
and 239.255.255.255.
(config service multicast test)> dst ip-address
(config service multicast test)>
6. Set the source interface for the route where multicast packets will arrive:
a. Use the ? to determine available interfaces:
(config service multicast test)> src_interface ?
Source interface: Where the multicast packets will arrive. IP routes
do not have an effect in the incoming stream.
Format:
/network/interface/defaultip
/network/interface/defaultlinklocal
/network/interface/eth1
/network/interface/eth2
/network/interface/loopback
Current value:
(config service multicast test)> src_interface
b. Set the interface. For example:
(config service multicast test)> src_interface /network/interface/eth1
(config service multicast test)>
7. Set a destination interface that the IX30 device will send mutlicast packets to:
a. Use the ? to determine available interfaces:
(config service multicast test)> src_interface ?
Destination interface: Which interface to send the multicast packets.
Format:
