Digi IX30 User Manual

User authentication LDAP
IX30 User Guide
742
The default is true.
6. Set the distinguished name (DN) that is used to bind to the LDAP server and search for users.
Leave this option unset if the server allows anonymous connections.
(config)> auth ldap bind_dn dn_value
(config)>
For example:
(config)> auth ldap bind_dn cn=user,dc=example,dc=com
(config)>
7. Set the password used to log into the LDAP server. Leave this option unset if the server allows
anonymous connections.
(config)> auth ldap bind_password password
(config)>
8. Set the distinguished name (DN) on the server to search for users. This can be the root of the
directory tree (for example, dc=example,dc=com) or a sub-tree (for example.
ou=People,dc=example,dc=com).
(config)> auth ldap base_dn value
(config)>
9. Set the login attribute:
(config)> auth ldap login_attribute value
(config)>
where value is the user attribute containing the login of the authenticated user. For example,
in the LDAP user configuration, the login attribute is uid. . If this attribute is not set, the user
will be denied access.
10. (Optional) Set the name of the user attribute that contains the list of IX30 authentication
groups that the authenticated user has access to. See LDAP user configuration for further
information about the group attribute.
(config)> auth ldap group_attribute value
(config)>
For example:
(config)> auth ldap group_attribute ou
(config)>
11. Configure the amount of time in seconds to wait for the LDAP server to respond.
(config)> auth ldap timeout value
(config)>
where value is any integer from 3 to 60. The default value is 3.

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
