Digi IX30 User Manual

Diagnostics Analyze network traffic
IX30 User Guide
942
iv. (Optional) Set the filter should ignore packets from this port:
(config network analyzer name filter port 0)> ignore true
(config network analyzer name filter port 0)>
By default, is option is set to false, which means that the filter will capture packets
from this port.
v. Repeat these steps to add additional port filters.
d. To create a filter that either captures or ignores packets from one or more specified MAC
addresses:
i. Add a new MAC address filter:
(config network analyzer name)> add filter mac_address end
(config network analyzer name filter mac_address 0)>
ii. Set the MAC address that should be be captured or ignored:
(config network analyzer name filter mac_address 0)> address value
(config network analyzer name filter mac_address 0)>
where value is the MAC address to be filtered, using colon-hexadecimal notation with
lower case, for example, 00:aa:11:bb:22:cc.
iii. Set whether the filter should apply to packets when the MACaddress is the source,
the destination, or both:
(config network analyzer name filter mac_address 0)> match value
(config network analyzer name filter mac_address 0)>
where value is one of:
n
source: The filter will apply to packets when the MACaddress is the source.
n
destination: The filter will apply to packets when the MAC address is the
destination.
n
either: The filter will apply to packets when the MACaddress is either the
source or the destination.
iv. (Optional) Set the filter should ignore packets from this port:
(config network analyzer name filter mac_address 0)> ignore true
(config network analyzer name filter mac_address 0)>
By default, is option is set to false, which means that the filter will capture packets
from this MAC address.
v. Repeat these steps to add additional MACaddresses.
e. To create a filter that either captures or ignores packets from one or more specified VLANs:
i. Add a new VLAN filter:
(config network analyzer name)> add filter vlan end
(config network analyzer name filter vlan 0)>

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
