Appendix I HYBRID Coater Service Manual ver1.1
168
I. I/O Assignment
This appendix shows more detailed information about assignment of I/O to certain functions
of the machine.
Paragraph 6 of Chapter 2 of the HYBRID Coater Reference Manual describes how I/O can
be defined for use in machine and product scripts. Which I/O name (Reference) refers to
which connector is shown in detail in this appendix.
DIGITAL IN
The 15 standard digital inputs are referenced as StdDigitalIn01 to StdDigitalIn16 which may
have dedicated functionality but can be used for other purposes as well.
Reference EL-04873 Name Remarks
StdDigitalIn01 P21 pins 1-4 Cont. Empty 1 Switch or 24Volt sensor with PNP or NPN output
StdDigitalIn02 P21 pins 5-8 Cont. Empty 2 Switch or 24Volt sensor with PNP or NPN output
StdDigitalIn03 P22 pins 1-4 Cont. Empty 3 Switch or 24Volt sensor with PNP or NPN output
StdDigitalIn04 P22 pins 5-8 Cont. Empty 4 Switch or 24Volt sensor with PNP or NPN output
StdDigitalIn05 P23 pins 1-4 Spare Input 1 Switch or 24Volt sensor with PNP or NPN output
StdDigitalIn06 P23 pins 5-8 Spare Input 2 Switch or 24Volt sensor with PNP or NPN output
StdDigitalIn07 P24 pins 1-4 Spare Input 3 Switch or 24Volt sensor with PNP or NPN output
StdDigitalIn08 P24 pins 5-8 Spare Input 4 Switch or 24Volt sensor with PNP or NPN output
StdDigitalIn09 P28 pins 1-2 Pushbutton 1 Illuminated pushbutton on front control panel
StdDigitalIn10 P28 pins 5-6 Pushbutton 2 Switch or Illuminated pushbutton
StdDigitalIn11 P4 pins 1-4 Limit 1 Conv.1 Vane switch EL-07164
StdDigitalIn12 P4 pins 5-8 Limit 2 Conv.1 Vane switch EL-07164
StdDigitalIn13 P5 pins 1-4 Limit 1 Conv.2 Vane switch EL-07164
StdDigitalIn14 P5 pins 5-8 Limit 2 Conv.2 Vane switch EL-07164
StdDigitalIn15 P27 pins 1-3 Alignment 1 Switch or 24Volt sensor with PNP output
StdDigitalIn16 P27 pins 4-6 Alignment 2 Switch or 24Volt sensor with PNP output
SENSOR IN
The 16 sensor inputs are referenced as StdSensorIn01 to StdSensorIn16 which may have
dedicated functionality but can be used for other purposes as well.
